CME 95HT
A Unique High Torque Rotary Drive designed to Turn 24” Diameter Augers
Width – 8’
Length – 36’ 1/2”
Folded Height – 12’ 3/4”
Mast – Up 38’ 1/2”
Retract Pressure – 62,830 lbs
Down Pressure – 33,135 lbs
Rotary Torque – 37,277 ft/lbs @65 RPM
The CME 95HT is the most powerful HSA rig available. It was purpose built with a unique High Torque Rotary Drive designed to turn 24” diameter augers. The result is significantly more torque than a standard CME 95.
Hollow Stem Auger / Mud / Air / Rotary / Wireline Coring Drill Rig
75” stroke, hydraulic vertical drive system
Retract rate up to 96 ft/min with Fine Hydraulic
Feed Control
Four forward gears and Four reverse with power shift transmission
Moyno 3L8 water/grout pump with high/low
gearing
Coated 470 gallon water tank
Hydraulic Auger Rack capable of carrying 130’ of 4 1/4” ID or 60’ of 6 1/4” ID Augers
Three hydraulic leveling jacks for stability during drilling
Calibrated above ground SPT auto-hammer for geotechnical sampling
